FlexVander LX9 E
FlexVander LX9 E is a control unit for field irrigation and pump management. It can be wall-mounted next to the installation or integrated in a cabinet when a DIN-rail version is used, and it makes it possible to start and stop up to 2 pumps, follow operation, and react quickly when something stops or fails.
The unit fits agricultural irrigation environments where daily operation needs to be visible without standing at the installation. In the Emiko App, the installation can be viewed on the map and pump status can be seen at a glance, with green for OK, orange for running, and red for fault.
FlexVander LX9 E supports GSM communication on 2G, 3G, and 4G/LTE, has internal battery backup for alarm handling during power failure, connects directly to 24V or 230V, and includes built-in relays for fast and simple installation. It can be used with or without a submersible pump and is built for robust long-life operation in the field.
FlexVander LX9 E is part of the Emiko EcoSystem. It combines pump control in the field with operation, monitoring, and alarm overview through the Emiko App as well as SMS and voice control, while access can be managed for the relevant company and users.
The solution can also be expanded with a mini weather station, selected inputs such as wind or water meters, and connected energy meters. With energy meters, electricity consumption can be followed per pump and per start/stop cycle, giving the farmer a clearer basis for reporting and understanding energy cost by field and irrigation run.
The package includes 1 x VikMote LX9, 1 x GSM antenna 4G 4.5 cm, and 1 x SIM card which can be activated immediately. With electronic pressure control and an added pressure transmitter, the irrigation system can also be controlled electronically with adjustable min/max limits for the desired pressure.
Key Benefits
- Flexible installation on wall or in cabinet with DIN-rail version
- Remote start and stop through the Emiko App, SMS, or voice control
- Fast overview of operation, status, and alarms
- Map view of installations in the field
- Clear fault indication with color-based status
- GSM communication on 2G, 3G, and 4G/LTE
- Internal battery backup for alarm handling during power failure
- Direct connection to 24V or 230V with built-in relays
- Optional energy measurement per pump and per start/stop cycle
- Better basis for reporting and understanding energy cost by field and irrigation run
- Expandable with mini weather station and selected meters
Platform & Service Model
- Powered by Emiko
- Start, stop, monitoring, and alarms are available through the Emiko App as well as SMS and voice control
- Access can be managed for the relevant company and users
Internal Reference:
1006816
